MKH 416-P48U3

Article No. 001511

Features03

  • Pressure gradient receiver with short interference tube
  • Hypercardioid at low and medium frequency
  • Above 2kHz approaches lobar pattern

Top Specs

  • ColorBlack
  • DimensionsØ 19 x 250 mm
  • Weight (g)500
  • Max. sound pressure level130 dB SPL
  • Polar patternSupercardioid, Lobar
  • Transducer principleRF condenser microphone

Tech Specs

Product
  • Transducer principle
    RF condenser microphone
  • Color
    Black
  • Polar pattern
    Supercardioid, Lobar
Frequency Specifications
  • Audio frequency response
    40 - 20,000 Hz
Acoustic Properties
  • Equivalent noise level (db)
    A-weighted 13 dB(A) CCIR-weighted 24 dB
  • Pick-up pattern
    super-cardioid/lobar
  • Max. sound pressure level
    130 dB SPL
Ambient Conditions
  • Operating temperature (C)
    -10 °C to 70 °C (14 °F to 158 °F)
Battery & Power
  • Charging current (mA)
    2 mA
Electrical Properties
  • Nominal impedance
    25 Ω
  • Min. terminating impedance
    800 Ω
Dimensions
  • Dimensions
    Ø 19 x 250 mm
  • Height (mm)
    350
  • Length (mm)
    135
  • Weight (g)
    500
  • Width (mm)
    66
  • Product height
    350
  • Product weight (g)
    175 g (0.39 lbs)
  • Product width
    approx. 19 mm (0.75")

Downloads17

  • Instruction manual - MKH 416
    .PDF
    ·
    382.84 KB
    Download
  • Instruction Manual - MKH 416
    .PDF
    ·
    382.61 KB
    Download
  • Instrucciones de manejo - MKH 416
    .PDF
    ·
    382.85 KB
    Download
  • Notice d'emploi - MKH 416
    .PDF
    ·
    385.8 KB
    Download
  • Istruzioni per l'uso - MKH 416
    .PDF
    ·
    376.12 KB
    Download
  • Betjeningsvejledning - MKH 416
    .PDF
    ·
    204.86 KB
    Download
  • Käyttöohje - MKH 416
    .PDF
    ·
    205.45 KB
    Download
  • Οδηγίες λειτουργίας - MKH 416
    .PDF
    ·
    252.98 KB
    Download
  • Gebruiksaanwijzing - MKH 416
    .PDF
    ·
    206.1 KB
    Download
  • Instrukcja obsługi - MKH 416
    .PDF
    ·
    206.86 KB
    Download
  • Manual de instruções - MKH 416
    .PDF
    ·
    205.72 KB
    Download
  • Bruksanvisning - MKH 416
    .PDF
    ·
    204.89 KB
    Download
  • Kullanım kılavuzu - MKH 416
    .PDF
    ·
    206.39 KB
    Download
  • Produktdatenblatt MKH 416
    .PDF
    ·
    191.52 KB
    Download
  • Product specification MKH 416
    .PDF
    ·
    191.6 KB
    Download
  • EU Declaration of conformity MKH series
    .PDF
    ·
    227.71 KB
    Download

What's in the box03

  • 1 MKH 416 P 48 U 3
  • 1 MZW 415 windshield
  • 1 MZQ 100 microphone clamp
