L 6000

Article No. 507300

L 6000 expands the Digital 6000 and Digital 9000 series with a practical and intelligent charging station. Up to four modules can be fitted as needed with two charging ports each for bodypack or handheld transmitter batteries. Three-color LEDs simplify the quick overview of the charging status. Can also be controlled via WSM software.

Practical, central, intelligent: The 19 inch 1 RU L 6000 charging station delivers power centrally and directly in the rack. Up to four freely selectable charging modules can accommodate two bodypack or handheld battery packs each (a total of 8 charging ports for battery packs BA 60, BA 61 or BA 62). Three-color LEDs give a quick overview of the charging status. The intelligent control system prevents heat buildup and also offers a mode that optimally charges the batteries for extended storage periods. The charging station L 6000 has a modular construction and is futureproof: Charging stations for future battery pack types can simply be retrofitted. Extensive details regarding temperature, remaining charging time, run times, charging cycles and battery quality can be retrieved via the Wireless Systems Manager (WSM).
Scroll to:

Features06

  • 19 inch charging station in 1 RU
  • Flexible configurations with loading modules for handheld transmitters or bodypack battery packs (Digital 6000 and Digital 9000)
  • Quick overview of charging status with three-color LEDs
  • Intelligent charging control with four fans for optimum cooling
  • Storage mode keeps battery packs in optimum charge condition for longer storage periods
  • Integrates into the Wireless Systems Manager

Top Specs

  • Dimensions44 x 483 x 373 mm
  • Weight (g)5.1 kg
  • Charging time (h)BA 60: 80 %: approx. 1:15 h, 100%: approx. 2:30h
  • Power consumption (Amp)Max. 85 W

Wireless Frequency Finder

Learn more
Wireless Frequency Finder

Tech Specs

Product
  • Display
    Multi-colored
Ambient Conditions
  • Operating relative humidity (≤ %)
    Max. 90 % at 40 °C
Battery & Power
  • Charging time (h)
    BA 60: 80 %: approx. 1:15 h, 100%: approx. 2:30h
  • Battery included
    N
  • Power consumption (Amp)
    Max. 85 W
  • Charging current (mA)
    2 A
  • Charging voltage (V)
    4.2 V
Technology
  • Network protocol
    IEEE 802.3-2002 (10/100 Mbit/s), shielded RJ-45 connection
Dimensions
  • Dimensions
    44 x 483 x 373 mm
  • Height (mm)
    175
  • Length (mm)
    550
  • Weight (g)
    5.1 kg
  • Width (mm)
    435
  • Product height
    175
  • Product length
    550
  • Product weight (g)
    5100
  • Product width
    435

Downloads24

chevron-up
  • Instruction manual - Digital 6000 (v4.0) (PDF)
    .PDF
    ·
    3.2 MB
    Download
  • Safety instructions EM 6000 | L6000
    .PDF
    ·
    837.86 KB
    Download
  • Compliance Sheet EM 6000 (incl. EM 6000 DANTE) | L 6000
    .PDF
    ·
    559.94 KB
    Download
  • Safety instructions LM 6060 | LM 6061 | LM 6062
    .PDF
    ·
    490.26 KB
    Download
  • L 6000 Release Notes v3.0.2
    .PDF
    ·
    105.52 KB
    Download
  • L 6000 Firmware Update V3.0.2
    .ZIP
    ·
    561.11 KB
    Download
  • L6000 Firmware version 3.0.1
    .ZIP
    ·
    561.24 KB
    Download
  • Digital6000_Frequencies_EN
    .PDF
    ·
    120.88 KB
    Download
  • 3D model LM 6060
    .STP
    ·
    6 MB
    Download
  • 3D model LM 6061
    .STP
    ·
    5.78 MB
    Download
  • 3D model L 6000
    .STP
    ·
    22.82 MB
    Download
  • 3D model LM 6062
    .STP
    ·
    6.1 MB
    Download
  • Outline dimensions L 6000 (DWG)
    .DWG
    ·
    2.42 MB
    Download
  • Outline dimensions L 6000 (PDF)
    .PDF
    ·
    283.02 KB
    Download
  • 3rd party control of Sennheiser products using media control protocols
    .PDF
    ·
    211.08 KB
    Download
    • L 6000 | LM 6060 | LM 6061 | LM 6062 | LM 6070 - Quick Guide
      .PDF
      ·
      3.74 MB
      Download
    • Product specification - L 6000
      .PDF
      ·
      306.8 KB
      Download
    • Sennheiser Sound Control Protocol Digital 6000 (EM 6000 | L 6000)
      .PDF
      ·
      547.8 KB
      Download
    • Architect's specification L 6000
      .DOCX
      ·
      13.86 KB
      Download

    What's in the box07

    • 1 L 6000
    • 1 Mains Cable (EU, UK or US plug)
    • 4 Dummy Cover incl. Screws
    • Quick Guide
    • Safety Guide
    • 2 Sticker
    • 4 Rubber Feet
